Upload 14 files

app.py

@@ -0,0 +1,241 @@
+import os
+
+import gradio as gr
+import numpy as np
+import torch
+from repvit_sam import SamAutomaticMaskGenerator, SamPredictor, sam_model_registry
+from PIL import ImageDraw
+from utils.tools import box_prompt, format_results, point_prompt
+from utils.tools_gradio import fast_process
+
+# Most of our demo code is from [FastSAM Demo](https://huggingface.co/spaces/An-619/FastSAM). Huge thanks for AN-619.
+
+device = torch.device("cuda" if torch.cuda.is_available() else "cpu")
+
+# Load the pre-trained model
+sam_checkpoint = "repvit_sam.pt"
+model_type = "repvit"
+
+repvit_sam = sam_model_registry[model_type](checkpoint=sam_checkpoint)
+repvit_sam = repvit_sam.to(device=device)
+repvit_sam.eval()
+
+mask_generator = SamAutomaticMaskGenerator(repvit_sam)
+predictor = SamPredictor(repvit_sam)
+
+# Description
+title = "<center><strong><font size='8'>RepViT-SAM<font></strong></center>"
+
+description_e = """This is a demo of [RepViT-SAM](https://github.com/THU-MIG/RepViT).
+
+                   We will provide box mode soon.
+
+                   Enjoy!
+
+              """
+
+description_p = """ Instructions for point mode
+
+                0. Restart by click the Restart button
+                1. Select a point with Add Mask for the foreground (Must)
+                2. Select a point with Remove Area for the background (Optional)
+                3. Click the Start Segmenting.
+
+                Github [link](https://github.com/THU-MIG/RepViT)
+
+              """
+
+examples = [
+    ["app/assets/picture3.jpg"],
+    ["app/assets/picture4.jpg"],
+    ["app/assets/picture6.jpg"],
+    ["app/assets/picture1.jpg"],
+]
+
+default_example = examples[0]
+
+css = "h1 { text-align: center } .about { text-align: justify; padding-left: 10%; padding-right: 10%; }"
+
+def segment_with_points(
+    image,
+    original_image,
+    input_size=1024,
+    better_quality=False,
+    withContours=True,
+    use_retina=True,
+    mask_random_color=True,
+):
+    global global_points
+    global global_point_label
+
+    input_size = int(input_size)
+    w, h = image.size
+    scale = input_size / max(w, h)
+    new_w = int(w * scale)
+    new_h = int(h * scale)
+    image = image.resize((new_w, new_h))
+
+    scaled_points = np.array(
+        [[int(x * scale) for x in point] for point in global_points]
+    )
+    scaled_point_label = np.array(global_point_label)
+
+    if scaled_points.size == 0 and scaled_point_label.size == 0:
+        print("No points selected")
+        return image, image
+
+    nd_image = np.array(original_image.resize((new_w, new_h)))
+    predictor.set_image(nd_image)
+    masks, scores, logits = predictor.predict(
+        point_coords=scaled_points,
+        point_labels=scaled_point_label,
+        multimask_output=False,
+    )
+
+    results = format_results(masks, scores, logits, 0)
+
+    annotations, _ = point_prompt(
+        results, scaled_points, scaled_point_label, new_h, new_w
+    )
+    annotations = np.array([annotations])
+
+    fig = fast_process(
+        annotations=annotations,
+        image=image,
+        device=device,
+        scale=(1024 // input_size),
+        better_quality=better_quality,
+        mask_random_color=mask_random_color,
+        bbox=None,
+        use_retina=use_retina,
+        withContours=withContours,
+    )
+
+    global_points = []
+    global_point_label = []
+    # return fig, None
+    return fig, original_image.resize((new_w, new_h))
+
+
+def get_points_with_draw(image, label, evt: gr.SelectData):
+    global global_points
+    global global_point_label
+
+    x, y = evt.index[0], evt.index[1]
+    point_radius, point_color = 15 * ((max(image.width, image.height)) / 1024), (255, 255, 0) if label == "Add Mask" else (
+        255,
+        0,
+        255,
+    )
+    global_points.append([x, y])
+    global_point_label.append(1 if label == "Add Mask" else 0)
+
+    # 创建一个可以在图像上绘图的对象
+    draw = ImageDraw.Draw(image)
+    draw.ellipse(
+        [(x - point_radius, y - point_radius), (x + point_radius, y + point_radius)],
+        fill=point_color,
+    )
+    return image
+
+
+cond_img_e = gr.Image(label="Input", value=default_example[0], type="pil")
+cond_img_p = gr.Image(label="Input with points", value=default_example[0], type="pil")
+
+segm_img_e = gr.Image(label="Segmented Image", interactive=False, type="pil")
+segm_img_p = gr.Image(
+    label="Segmented Image with points", interactive=True, type="pil"
+)
+
+global_points = []
+global_point_label = []
+
+input_size_slider = gr.components.Slider(
+    minimum=512,
+    maximum=1024,
+    value=1024,
+    step=64,
+    label="Input_size",
+    info="Our model was trained on a size of 1024",
+)
+
+with gr.Blocks(css=css, title="RepViT-SAM") as demo:
+    from PIL import Image
+    original_image = gr.State(value=Image.open(default_example[0]).convert('RGB'))
+
+    with gr.Row():
+        with gr.Column(scale=1):
+            # Title
+            gr.Markdown(title)
+
+    with gr.Tab("Point mode"):
+        # Images
+        with gr.Row(variant="panel"):
+            with gr.Column(scale=1):
+                cond_img_p.render()
+
+            with gr.Column(scale=1):
+                segm_img_p.render()
+
+        # Submit & Clear
+        with gr.Row():
+            with gr.Column():
+                with gr.Row():
+                    add_or_remove = gr.Radio(
+                        ["Add Mask", "Remove Area"],
+                        value="Add Mask",
+                    )
+
+                    with gr.Column():
+                        segment_btn_p = gr.Button(
+                            "Start segmenting!", variant="primary"
+                        )
+                        clear_btn_p = gr.Button("Restart", variant="secondary")
+
+                gr.Markdown("Try some of the examples below ⬇️")
+
+                gr.Examples(
+                    examples=examples,
+                    inputs=[cond_img_p],
+                    fn=lambda x: x,
+                    outputs=[original_image],
+                    # fn=segment_with_points,
+                    # cache_examples=True,
+                    examples_per_page=4,
+                    run_on_click=True
+                )
+
+            with gr.Column():
+                # Description
+                gr.Markdown(description_p)
+
+    cond_img_p.select(get_points_with_draw, [cond_img_p, add_or_remove], cond_img_p)
+    cond_img_p.upload(lambda x: x, inputs=[cond_img_p], outputs=[original_image])
+
+    # segment_btn_e.click(
+    #     segment_everything,
+    #     inputs=[
+    #         cond_img_e,
+    #         input_size_slider,
+    #         mor_check,
+    #         contour_check,
+    #         retina_check,
+    #     ],
+    #     outputs=segm_img_e,
+    # )
+
+    segment_btn_p.click(
+        segment_with_points, inputs=[cond_img_p, original_image], outputs=[segm_img_p, cond_img_p]
+    )
+
+    def clear():
+        return None, None
+
+    def clear_text():
+        return None, None, None
+
+    # clear_btn_e.click(clear, outputs=[cond_img_e, segm_img_e])
+    clear_btn_p.click(clear, outputs=[cond_img_p, segm_img_p])
+
+demo.queue()
+demo.launch()

repvit_sam.pt

@@ -0,0 +1,3 @@
+version https://git-lfs.github.com/spec/v1
+oid sha256:1fd2867cf669e6d89b1c91d0eb883d83ef4bcc590143dd2ca35e2705b21a4f2f
+size 110032539

requirements.txt

@@ -0,0 +1,5 @@
+torch
+torchvision
+timm
+opencv-python
+git+https://[email protected]/THU-RepViT/RepViT.git#subdirectory=sam

utils/tools.py

@@ -0,0 +1,406 @@
+import os
+import sys
+
+import cv2
+import matplotlib.pyplot as plt
+import numpy as np
+import torch
+from PIL import Image
+
+
+def convert_box_xywh_to_xyxy(box):
+    x1 = box[0]
+    y1 = box[1]
+    x2 = box[0] + box[2]
+    y2 = box[1] + box[3]
+    return [x1, y1, x2, y2]
+
+
+def segment_image(image, bbox):
+    image_array = np.array(image)
+    segmented_image_array = np.zeros_like(image_array)
+    x1, y1, x2, y2 = bbox
+    segmented_image_array[y1:y2, x1:x2] = image_array[y1:y2, x1:x2]
+    segmented_image = Image.fromarray(segmented_image_array)
+    black_image = Image.new("RGB", image.size, (255, 255, 255))
+    # transparency_mask = np.zeros_like((), dtype=np.uint8)
+    transparency_mask = np.zeros(
+        (image_array.shape[0], image_array.shape[1]), dtype=np.uint8
+    )
+    transparency_mask[y1:y2, x1:x2] = 255
+    transparency_mask_image = Image.fromarray(transparency_mask, mode="L")
+    black_image.paste(segmented_image, mask=transparency_mask_image)
+    return black_image
+
+
+def format_results(masks, scores, logits, filter=0):
+    annotations = []
+    n = len(scores)
+    for i in range(n):
+        annotation = {}
+
+        mask = masks[i]
+        tmp = np.where(mask != 0)
+        if np.sum(mask) < filter:
+            continue
+        annotation["id"] = i
+        annotation["segmentation"] = mask
+        annotation["bbox"] = [
+            np.min(tmp[0]),
+            np.min(tmp[1]),
+            np.max(tmp[1]),
+            np.max(tmp[0]),
+        ]
+        annotation["score"] = scores[i]
+        annotation["area"] = annotation["segmentation"].sum()
+        annotations.append(annotation)
+    return annotations
+
+
+def filter_masks(annotations):  # filter the overlap mask
+    annotations.sort(key=lambda x: x["area"], reverse=True)
+    to_remove = set()
+    for i in range(0, len(annotations)):
+        a = annotations[i]
+        for j in range(i + 1, len(annotations)):
+            b = annotations[j]
+            if i != j and j not in to_remove:
+                # check if
+                if b["area"] < a["area"]:
+                    if (a["segmentation"] & b["segmentation"]).sum() / b[
+                        "segmentation"
+                    ].sum() > 0.8:
+                        to_remove.add(j)
+
+    return [a for i, a in enumerate(annotations) if i not in to_remove], to_remove
+
+
+def get_bbox_from_mask(mask):
+    mask = mask.astype(np.uint8)
+    contours, hierarchy = cv2.findContours(
+        mask, cv2.RETR_EXTERNAL, cv2.CHAIN_APPROX_SIMPLE
+    )
+    x1, y1, w, h = cv2.boundingRect(contours[0])
+    x2, y2 = x1 + w, y1 + h
+    if len(contours) > 1:
+        for b in contours:
+            x_t, y_t, w_t, h_t = cv2.boundingRect(b)
+            # 将多个bbox合并成一个
+            x1 = min(x1, x_t)
+            y1 = min(y1, y_t)
+            x2 = max(x2, x_t + w_t)
+            y2 = max(y2, y_t + h_t)
+        h = y2 - y1
+        w = x2 - x1
+    return [x1, y1, x2, y2]
+
+
+def fast_process(
+    annotations, args, mask_random_color, bbox=None, points=None, edges=False
+):
+    if isinstance(annotations[0], dict):
+        annotations = [annotation["segmentation"] for annotation in annotations]
+    result_name = os.path.basename(args.img_path)
+    image = cv2.imread(args.img_path)
+    image = cv2.cvtColor(image, cv2.COLOR_BGR2RGB)
+    original_h = image.shape[0]
+    original_w = image.shape[1]
+    if sys.platform == "darwin":
+        plt.switch_backend("TkAgg")
+    plt.figure(figsize=(original_w / 100, original_h / 100))
+    # Add subplot with no margin.
+    plt.subplots_adjust(top=1, bottom=0, right=1, left=0, hspace=0, wspace=0)
+    plt.margins(0, 0)
+    plt.gca().xaxis.set_major_locator(plt.NullLocator())
+    plt.gca().yaxis.set_major_locator(plt.NullLocator())
+    plt.imshow(image)
+    if args.better_quality == True:
+        if isinstance(annotations[0], torch.Tensor):
+            annotations = np.array(annotations.cpu())
+        for i, mask in enumerate(annotations):
+            mask = cv2.morphologyEx(
+                mask.astype(np.uint8), cv2.MORPH_CLOSE, np.ones((3, 3), np.uint8)
+            )
+            annotations[i] = cv2.morphologyEx(
+                mask.astype(np.uint8), cv2.MORPH_OPEN, np.ones((8, 8), np.uint8)
+            )
+    if args.device == "cpu":
+        annotations = np.array(annotations)
+        fast_show_mask(
+            annotations,
+            plt.gca(),
+            random_color=mask_random_color,
+            bbox=bbox,
+            points=points,
+            point_label=args.point_label,
+            retinamask=args.retina,
+            target_height=original_h,
+            target_width=original_w,
+        )
+    else:
+        if isinstance(annotations[0], np.ndarray):
+            annotations = torch.from_numpy(annotations)
+        fast_show_mask_gpu(
+            annotations,
+            plt.gca(),
+            random_color=args.randomcolor,
+            bbox=bbox,
+            points=points,
+            point_label=args.point_label,
+            retinamask=args.retina,
+            target_height=original_h,
+            target_width=original_w,
+        )
+    if isinstance(annotations, torch.Tensor):
+        annotations = annotations.cpu().numpy()
+    if args.withContours == True:
+        contour_all = []
+        temp = np.zeros((original_h, original_w, 1))
+        for i, mask in enumerate(annotations):
+            if type(mask) == dict:
+                mask = mask["segmentation"]
+            annotation = mask.astype(np.uint8)
+            if args.retina == False:
+                annotation = cv2.resize(
+                    annotation,
+                    (original_w, original_h),
+                    interpolation=cv2.INTER_NEAREST,
+                )
+            contours, hierarchy = cv2.findContours(
+                annotation, cv2.RETR_TREE, cv2.CHAIN_APPROX_SIMPLE
+            )
+            for contour in contours:
+                contour_all.append(contour)
+        cv2.drawContours(temp, contour_all, -1, (255, 255, 255), 2)
+        color = np.array([0 / 255, 0 / 255, 255 / 255, 0.8])
+        contour_mask = temp / 255 * color.reshape(1, 1, -1)
+        plt.imshow(contour_mask)
+
+    save_path = args.output
+    if not os.path.exists(save_path):
+        os.makedirs(save_path)
+    plt.axis("off")
+    fig = plt.gcf()
+    plt.draw()
+
+    try:
+        buf = fig.canvas.tostring_rgb()
+    except AttributeError:
+        fig.canvas.draw()
+        buf = fig.canvas.tostring_rgb()
+
+    cols, rows = fig.canvas.get_width_height()
+    img_array = np.fromstring(buf, dtype=np.uint8).reshape(rows, cols, 3)
+    cv2.imwrite(
+        os.path.join(save_path, result_name), cv2.cvtColor(img_array, cv2.COLOR_RGB2BGR)
+    )
+
+
+# CPU post process
+def fast_show_mask(
+    annotation,
+    ax,
+    random_color=False,
+    bbox=None,
+    points=None,
+    point_label=None,
+    retinamask=True,
+    target_height=960,
+    target_width=960,
+):
+    msak_sum = annotation.shape[0]
+    height = annotation.shape[1]
+    weight = annotation.shape[2]
+    # 将annotation 按照面积 排序
+    areas = np.sum(annotation, axis=(1, 2))
+    sorted_indices = np.argsort(areas)
+    annotation = annotation[sorted_indices]
+
+    index = (annotation != 0).argmax(axis=0)
+    if random_color == True:
+        color = np.random.random((msak_sum, 1, 1, 3))
+    else:
+        color = np.ones((msak_sum, 1, 1, 3)) * np.array(
+            [30 / 255, 144 / 255, 255 / 255]
+        )
+    transparency = np.ones((msak_sum, 1, 1, 1)) * 0.6
+    visual = np.concatenate([color, transparency], axis=-1)
+    mask_image = np.expand_dims(annotation, -1) * visual
+
+    show = np.zeros((height, weight, 4))
+    h_indices, w_indices = np.meshgrid(
+        np.arange(height), np.arange(weight), indexing="ij"
+    )
+    indices = (index[h_indices, w_indices], h_indices, w_indices, slice(None))
+    # 使用向量化索引更新show的值
+    show[h_indices, w_indices, :] = mask_image[indices]
+    if bbox is not None:
+        x1, y1, x2, y2 = bbox
+        ax.add_patch(
+            plt.Rectangle(
+                (x1, y1), x2 - x1, y2 - y1, fill=False, edgecolor="b", linewidth=1
+            )
+        )
+    # draw point
+    if points is not None:
+        plt.scatter(
+            [point[0] for i, point in enumerate(points) if point_label[i] == 1],
+            [point[1] for i, point in enumerate(points) if point_label[i] == 1],
+            s=20,
+            c="y",
+        )
+        plt.scatter(
+            [point[0] for i, point in enumerate(points) if point_label[i] == 0],
+            [point[1] for i, point in enumerate(points) if point_label[i] == 0],
+            s=20,
+            c="m",
+        )
+
+    if retinamask == False:
+        show = cv2.resize(
+            show, (target_width, target_height), interpolation=cv2.INTER_NEAREST
+        )
+    ax.imshow(show)
+
+
+def fast_show_mask_gpu(
+    annotation,
+    ax,
+    random_color=False,
+    bbox=None,
+    points=None,
+    point_label=None,
+    retinamask=True,
+    target_height=960,
+    target_width=960,
+):
+    msak_sum = annotation.shape[0]
+    height = annotation.shape[1]
+    weight = annotation.shape[2]
+    areas = torch.sum(annotation, dim=(1, 2))
+    sorted_indices = torch.argsort(areas, descending=False)
+    annotation = annotation[sorted_indices]
+    # 找每个位置第一个非零值下标
+    index = (annotation != 0).to(torch.long).argmax(dim=0)
+    if random_color == True:
+        color = torch.rand((msak_sum, 1, 1, 3)).to(annotation.device)
+    else:
+        color = torch.ones((msak_sum, 1, 1, 3)).to(annotation.device) * torch.tensor(
+            [30 / 255, 144 / 255, 255 / 255]
+        ).to(annotation.device)
+    transparency = torch.ones((msak_sum, 1, 1, 1)).to(annotation.device) * 0.6
+    visual = torch.cat([color, transparency], dim=-1)
+    mask_image = torch.unsqueeze(annotation, -1) * visual
+    # 按index取数，index指每个位置选哪个batch的数，把mask_image转成一个batch的形式
+    show = torch.zeros((height, weight, 4)).to(annotation.device)
+    h_indices, w_indices = torch.meshgrid(
+        torch.arange(height), torch.arange(weight), indexing="ij"
+    )
+    indices = (index[h_indices, w_indices], h_indices, w_indices, slice(None))
+    # 使用向量化索引更新show的值
+    show[h_indices, w_indices, :] = mask_image[indices]
+    show_cpu = show.cpu().numpy()
+    if bbox is not None:
+        x1, y1, x2, y2 = bbox
+        ax.add_patch(
+            plt.Rectangle(
+                (x1, y1), x2 - x1, y2 - y1, fill=False, edgecolor="b", linewidth=1
+            )
+        )
+    # draw point
+    if points is not None:
+        plt.scatter(
+            [point[0] for i, point in enumerate(points) if point_label[i] == 1],
+            [point[1] for i, point in enumerate(points) if point_label[i] == 1],
+            s=20,
+            c="y",
+        )
+        plt.scatter(
+            [point[0] for i, point in enumerate(points) if point_label[i] == 0],
+            [point[1] for i, point in enumerate(points) if point_label[i] == 0],
+            s=20,
+            c="m",
+        )
+    if retinamask == False:
+        show_cpu = cv2.resize(
+            show_cpu, (target_width, target_height), interpolation=cv2.INTER_NEAREST
+        )
+    ax.imshow(show_cpu)
+
+
+def crop_image(annotations, image_like):
+    if isinstance(image_like, str):
+        image = Image.open(image_like)
+    else:
+        image = image_like
+    ori_w, ori_h = image.size
+    mask_h, mask_w = annotations[0]["segmentation"].shape
+    if ori_w != mask_w or ori_h != mask_h:
+        image = image.resize((mask_w, mask_h))
+    cropped_boxes = []
+    cropped_images = []
+    not_crop = []
+    filter_id = []
+    # annotations, _ = filter_masks(annotations)
+    # filter_id = list(_)
+    for _, mask in enumerate(annotations):
+        if np.sum(mask["segmentation"]) <= 100:
+            filter_id.append(_)
+            continue
+        bbox = get_bbox_from_mask(mask["segmentation"])  # mask 的 bbox
+        cropped_boxes.append(segment_image(image, bbox))  # 保存裁剪的图片
+        # cropped_boxes.append(segment_image(image,mask["segmentation"]))
+        cropped_images.append(bbox)  # 保存裁剪的图片的bbox
+
+    return cropped_boxes, cropped_images, not_crop, filter_id, annotations
+
+
+def box_prompt(masks, bbox, target_height, target_width):
+    h = masks.shape[1]
+    w = masks.shape[2]
+    if h != target_height or w != target_width:
+        bbox = [
+            int(bbox[0] * w / target_width),
+            int(bbox[1] * h / target_height),
+            int(bbox[2] * w / target_width),
+            int(bbox[3] * h / target_height),
+        ]
+    bbox[0] = round(bbox[0]) if round(bbox[0]) > 0 else 0
+    bbox[1] = round(bbox[1]) if round(bbox[1]) > 0 else 0
+    bbox[2] = round(bbox[2]) if round(bbox[2]) < w else w
+    bbox[3] = round(bbox[3]) if round(bbox[3]) < h else h
+
+    # IoUs = torch.zeros(len(masks), dtype=torch.float32)
+    bbox_area = (bbox[3] - bbox[1]) * (bbox[2] - bbox[0])
+
+    masks_area = torch.sum(masks[:, bbox[1] : bbox[3], bbox[0] : bbox[2]], dim=(1, 2))
+    orig_masks_area = torch.sum(masks, dim=(1, 2))
+
+    union = bbox_area + orig_masks_area - masks_area
+    IoUs = masks_area / union
+    max_iou_index = torch.argmax(IoUs)
+
+    return masks[max_iou_index].cpu().numpy(), max_iou_index
+
+
+def point_prompt(masks, points, point_label, target_height, target_width):  # numpy 处理
+    h = masks[0]["segmentation"].shape[0]
+    w = masks[0]["segmentation"].shape[1]
+    if h != target_height or w != target_width:
+        points = [
+            [int(point[0] * w / target_width), int(point[1] * h / target_height)]
+            for point in points
+        ]
+    onemask = np.zeros((h, w))
+    for i, annotation in enumerate(masks):
+        if type(annotation) == dict:
+            mask = annotation["segmentation"]
+        else:
+            mask = annotation
+        for i, point in enumerate(points):
+            if mask[point[1], point[0]] == 1 and point_label[i] == 1:
+                onemask += mask
+            if mask[point[1], point[0]] == 1 and point_label[i] == 0:
+                onemask -= mask
+    onemask = onemask >= 1
+    return onemask, 0

utils/tools_gradio.py

@@ -0,0 +1,192 @@
+import cv2
+import matplotlib.pyplot as plt
+import numpy as np
+import torch
+from PIL import Image
+
+
+def fast_process(
+    annotations,
+    image,
+    device,
+    scale,
+    better_quality=False,
+    mask_random_color=True,
+    bbox=None,
+    use_retina=True,
+    withContours=True,
+):
+    if isinstance(annotations[0], dict):
+        annotations = [annotation["segmentation"] for annotation in annotations]
+
+    original_h = image.height
+    original_w = image.width
+    if better_quality:
+        if isinstance(annotations[0], torch.Tensor):
+            annotations = np.array(annotations.cpu())
+        for i, mask in enumerate(annotations):
+            mask = cv2.morphologyEx(
+                mask.astype(np.uint8), cv2.MORPH_CLOSE, np.ones((3, 3), np.uint8)
+            )
+            annotations[i] = cv2.morphologyEx(
+                mask.astype(np.uint8), cv2.MORPH_OPEN, np.ones((8, 8), np.uint8)
+            )
+    if device == "cpu":
+        annotations = np.array(annotations)
+        inner_mask = fast_show_mask(
+            annotations,
+            plt.gca(),
+            random_color=mask_random_color,
+            bbox=bbox,
+            retinamask=use_retina,
+            target_height=original_h,
+            target_width=original_w,
+        )
+    else:
+        if isinstance(annotations[0], np.ndarray):
+            annotations = np.array(annotations)
+            annotations = torch.from_numpy(annotations)
+        inner_mask = fast_show_mask_gpu(
+            annotations,
+            plt.gca(),
+            random_color=mask_random_color,
+            bbox=bbox,
+            retinamask=use_retina,
+            target_height=original_h,
+            target_width=original_w,
+        )
+    if isinstance(annotations, torch.Tensor):
+        annotations = annotations.cpu().numpy()
+
+    if withContours:
+        contour_all = []
+        temp = np.zeros((original_h, original_w, 1))
+        for i, mask in enumerate(annotations):
+            if type(mask) == dict:
+                mask = mask["segmentation"]
+            annotation = mask.astype(np.uint8)
+            if use_retina == False:
+                annotation = cv2.resize(
+                    annotation,
+                    (original_w, original_h),
+                    interpolation=cv2.INTER_NEAREST,
+                )
+            contours, _ = cv2.findContours(
+                annotation, cv2.RETR_TREE, cv2.CHAIN_APPROX_SIMPLE
+            )
+            for contour in contours:
+                contour_all.append(contour)
+        cv2.drawContours(temp, contour_all, -1, (255, 255, 255), 2 // scale)
+        color = np.array([0 / 255, 0 / 255, 255 / 255, 0.9])
+        contour_mask = temp / 255 * color.reshape(1, 1, -1)
+
+    image = image.convert("RGBA")
+    overlay_inner = Image.fromarray((inner_mask * 255).astype(np.uint8), "RGBA")
+    image.paste(overlay_inner, (0, 0), overlay_inner)
+
+    if withContours:
+        overlay_contour = Image.fromarray((contour_mask * 255).astype(np.uint8), "RGBA")
+        image.paste(overlay_contour, (0, 0), overlay_contour)
+
+    return image
+
+
+# CPU post process
+def fast_show_mask(
+    annotation,
+    ax,
+    random_color=False,
+    bbox=None,
+    retinamask=True,
+    target_height=960,
+    target_width=960,
+):
+    mask_sum = annotation.shape[0]
+    height = annotation.shape[1]
+    weight = annotation.shape[2]
+    # 将annotation 按照面积 排序
+    areas = np.sum(annotation, axis=(1, 2))
+    sorted_indices = np.argsort(areas)[::1]
+    annotation = annotation[sorted_indices]
+
+    index = (annotation != 0).argmax(axis=0)
+    if random_color == True:
+        color = np.random.random((mask_sum, 1, 1, 3))
+    else:
+        color = np.ones((mask_sum, 1, 1, 3)) * np.array(
+            [30 / 255, 144 / 255, 255 / 255]
+        )
+    transparency = np.ones((mask_sum, 1, 1, 1)) * 0.6
+    visual = np.concatenate([color, transparency], axis=-1)
+    mask_image = np.expand_dims(annotation, -1) * visual
+
+    mask = np.zeros((height, weight, 4))
+
+    h_indices, w_indices = np.meshgrid(
+        np.arange(height), np.arange(weight), indexing="ij"
+    )
+    indices = (index[h_indices, w_indices], h_indices, w_indices, slice(None))
+
+    mask[h_indices, w_indices, :] = mask_image[indices]
+    if bbox is not None:
+        x1, y1, x2, y2 = bbox
+        ax.add_patch(
+            plt.Rectangle(
+                (x1, y1), x2 - x1, y2 - y1, fill=False, edgecolor="b", linewidth=1
+            )
+        )
+
+    if retinamask == False:
+        mask = cv2.resize(
+            mask, (target_width, target_height), interpolation=cv2.INTER_NEAREST
+        )
+
+    return mask
+
+
+def fast_show_mask_gpu(
+    annotation,
+    ax,
+    random_color=False,
+    bbox=None,
+    retinamask=True,
+    target_height=960,
+    target_width=960,
+):
+    device = annotation.device
+    mask_sum = annotation.shape[0]
+    height = annotation.shape[1]
+    weight = annotation.shape[2]
+    areas = torch.sum(annotation, dim=(1, 2))
+    sorted_indices = torch.argsort(areas, descending=False)
+    annotation = annotation[sorted_indices]
+    # 找每个位置第一个非零值下标
+    index = (annotation != 0).to(torch.long).argmax(dim=0)
+    if random_color == True:
+        color = torch.rand((mask_sum, 1, 1, 3)).to(device)
+    else:
+        color = torch.ones((mask_sum, 1, 1, 3)).to(device) * torch.tensor(
+            [30 / 255, 144 / 255, 255 / 255]
+        ).to(device)
+    transparency = torch.ones((mask_sum, 1, 1, 1)).to(device) * 0.6
+    visual = torch.cat([color, transparency], dim=-1)
+    mask_image = torch.unsqueeze(annotation, -1) * visual
+    # 按index取数，index指每个位置选哪个batch的数，把mask_image转成一个batch的形式
+    mask = torch.zeros((height, weight, 4)).to(device)
+    h_indices, w_indices = torch.meshgrid(torch.arange(height), torch.arange(weight))
+    indices = (index[h_indices, w_indices], h_indices, w_indices, slice(None))
+    # 使用向量化索引更新show的值
+    mask[h_indices, w_indices, :] = mask_image[indices]
+    mask_cpu = mask.cpu().numpy()
+    if bbox is not None:
+        x1, y1, x2, y2 = bbox
+        ax.add_patch(
+            plt.Rectangle(
+                (x1, y1), x2 - x1, y2 - y1, fill=False, edgecolor="b", linewidth=1
+            )
+        )
+    if retinamask == False:
+        mask_cpu = cv2.resize(
+            mask_cpu, (target_width, target_height), interpolation=cv2.INTER_NEAREST
+        )
+    return mask_cpu
